Conveyor Systems

Bulk Transport System

The Gulf Center Belt Conveyor Series is designed for high-capacity bulk material transport with a simple structure, standardized components, and easy maintenance.

Widely used across mining, metallurgy, construction, and industrial sectors, our conveyors efficiently handle both raw materials and finished products.

The system can operate as a single conveyor line or be configured into multi-stage or inclined setups, seamlessly integrating with other process equipment to meet diverse production layout requirements.

Heavy-duty belt conveyor systems engineered for efficient bulk material transport, smooth operation, and easy integration into industrial production lines.

The Gulf Center Standard Belt Conveyor Series is engineered for efficient and reliable bulk material transport across various industrial applications.
Each system is built with high-quality structural steel and features a durable design for long-term operation under demanding conditions.

The conveyor system consists of the following key components:

Frame – fabricated from heavy-duty steel plates for maximum structural integrity.

Conveying Belt – high-strength belt designed for continuous material flow.

Carrier Rollers – precisely aligned rollers ensuring smooth and stable belt movement.

Drive Drum & Tension Drum – maintain belt tension and consistent power transmission.

Drive Unit – motorized pulley or geared drive system providing reliable motion.

Support Legs & Fixing Structure – create an optimized incline between front and rear sections for efficient material discharge.

Each conveyor can be configured for horizontal or inclined operation and integrated into complete material handling systems.
Designed and fabricated in Kuwait, every Gulf Center conveyor meets ISO-certified QA/QC and KOC-approved standards, ensuring high performance and easy maintenance.

Lacing made or rolled steel profiles

Motor-reducer driver direct to drums, designed to absorve the maximal efforts that may be produced

Perpetual greased rollers

Wide surveying walkways

Anti-return device included

First quality belts

Open or dust-tight (depending on feeding machine) back reception guide Vulcanized drums

Bulk Transport System
Specifications – Gulf Center Standard Conveyor Belt
Belt Width (mm)	Length (m) / Power (kW)	Speed (m/s)	Capacity (t/h)
500	≤12 m → 4 kW12–20 m → 5.5–7.5 kW20–30 m → 11–15 kW	1.3–1.6	40–80
650	≤12 m → 4 kW12–20 m → 5.5–11 kW20–30 m → 11–18 kW	1.3–1.6	130–320
800	≤6 m → 5.5 kW6–15 m → 5.5–11 kW15–30 m → 11–15 kW	1.3–1.6	280–540
1000	≤10 m → 5.5 kW10–20 m → 7.5–11 kW20–40 m → 11–12 kW	1.3–2.0	430–850
1200	≤10 m → 7.5 kW10–20 m → 11 kW20–40 m → 15–30 kW	1.3–2.0	655–1280
